מפרט
דגם מעבד
Intel Core i7-1265UE (10 Cores | 12 Threads | Base GHz 3.50 | Max GHz 4.70 | 12 MB Cache | Base Power 15 W | Turbo Power 55 W)
סדרת מעבד (CPU)
Intel Core i7
סוג זכרון
DDR5
גודל זיכרון (RAM)
לא כלול - עד 64 גי'גה
חריצי זיכרון
2
נפח איחסון
Not included M.2
כרטיס מסך
Intel Iris Xe
USB Type-C
2
USB 3.2
2
USB 2.0
4
חיבור גרפי
VGA
\ HDMI
חיבורי תקשורת
LAN 2.5 Gigabit
סוג דיסק
M.2 2230
\ M.2 2242
\ M.2 2280
הערות
H=44 W=195 D=150 mm | Weight 1 Kg
מידע
Key Applications
- Industrial Automation, Retail
- Smart Medical Expert Systems
- Digital Signage Kiosk, Interactive info system
- IoT Gateway for Smart Factory
- Smart Building, Security and Surveillance
Key Features
- 12th Generation Intel® Celeron® 7305E&Core™ i7-1265UE/i5-1245UE/i3-1215UE
- 2x DDR5-4800MHz Non-ECC SO-DIMM max 64GB
- M.2 M/B/E-Key with Nano SIM Card Slot
- 2x LAN 2.5GbE
- Fanless (Op. Temperature 0C ~ +50C)
- 4 Independent Displays: HDMI2.0b/1.4b + DP 1.4a (Alt mode USB Typ-C)
Power Configurations
- Force power-on by jumper
- Control of power-on for recovery from AC power loss
- DC 12V~24V Wide power range input
- CPU thermal trip support for processor protection
- ACPI Power Management
Hardware
- Trusted Platform Module (TPM) 2.0
