Asus Prime B760M-K D4

P/N:

90MB1DS0-M1EAY0

Warranty:

3 Years

Manufacturer:

Asus Prime B760M-K D4 an Intel B760 LGA 1700 mATX motherboard with PCIe 4.0, two PCIe 4.0 M.2 slots, DDR4, Realtek 2.5Gb Ethernet, VGA, HDMI, SATA 6 Gbps, front USB 3.2 Gen 1, Aura Sync. 90MB1DS0-M1EAY0
Specification
Information

Specification

Chipset

Intel B760

Socket

1700

Memory Type

DDR4

MB Form Factor

Micro ATX

Graphics Interface

VGA
\ HDMI

Network Connections

LAN 2.5 Gigabit

Front USB Connector

USB 2.0
\ USB 3.2

RAID

0,1,5,10

Audio O.B

3 port

DDR4 Slots

PCI-E x16

PCI-E x4

USB 3.2

USB 2.0

Storage Interface

SATA3
\ M.2 PCIe

SATA3 Ports

M.2 PCIe Connectors

MB Expansion Slots

Trusted Platform Module (TPM)
\ PCIe 4.0 x16
\ PCIe 4.0 x4

COM Port

Optional

Information

Asus Prime B760M-K D4

ASUS Prime series motherboards are expertly engineered to unleash the full potential of 14th Gen Intel® Core™ Processors.

Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options,

PRIME B760M-K D4 provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.

This platform delivers the power and connectivity that advanced AI PC applications demand.

Ready for Advanced AI PC:

Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications

Intel® LGA 1700 Socket:

Ready for 14th, 13th and 12th Gen Intel® processors

Ultrafast Connectivity:

PCIe 4.0, two PCIe 4.0 M.2 slots, Realtek 2.5Gb Ethernet and front USB 3.2 Gen 1 support

Comprehensive Cooling:

VRM heatsink, PCH heatsink, hybrid fan headers and Fan Xpert

Aura Sync RGB Lighting:

Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware
