Supermicro X13SEM-TF, 5th/4th Gen Intel Xeon Scalable processors, Single Socket LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP, Intel C741 Chipset
מפרט
ערכת שבבים
Intel C741
תושבת מעבד
4677
סוג זכרון
DDR5
תצורת לוח
Micro ATX
חיבור גרפי
VGA
חיבורי תקשורת
LAN 1 Gigabit
\ LAN 10 Gigabit
חיבור USB קדמי
USB 2.0
\ USB 3.2
RAID
0,1,5,10
סלוטים DDR5
8
PCI-E x16
2
PCI-E x16 (x8) Slot
1xPCIe 5.0 x8 | 4xPCIe 5.0 x8 MCIO connector
USB 3.2
5
USB 2.0
6
ממשק אחסון
SATA3
\ M.2 PCIe
חיבורי SATA3
10
חיבורי M.2 PCIe
2
חריצי הרחבה
Trusted Platform Module (TPM)
\ PCIe 4.0 x16, mode x8
\ PCIe 5.0 x16 slot
חיבור סיריאלי COM
יש
מידע
Supermicro X13SEM-TF
Key Features
5th/4th Gen Intel® Xeon® Scalable processors, Single Socket LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP •
Intel C741® Chipset •
Up to 2TB 3DS ECC RDIMM, DDR5-5600MT/s (1DPC) in 8 DIMM slots •
8xNVMe ports PCIe 5.0 x4 via 4 MCIO connectors •
1xPCIe 5.0 x8, 2 PCIe 5.0 x16, 4 PCIe 5.0 x8 MCIO connectors •
M.2 Interface: 2 PCIe 4.0 x2 •
M.2 Form Factor: 2280, 22110 •
M.2 Key: M-Key •
Dual LAN with 10GBase-T with Intel® X550 •
5xUSB 3.2 Gen1 (2 rear, 1 Type-A, 2 via header), 6 USB 2.0 (2 rear, 4 via headers) •
Intel® C741 controller for 10 SATA3 (6 Gbps) ports or 2 PCIe 3.0 x4 NVMe + 2 SATA3 ports; RAID (SATA) 0,1,5,10 •
