Single Channel H.264 Video Encoder with PoE

Single Channel H.264 Video Encoder with PoE

מק"ט:

DVS-310-1

אחריות:

שנתיים

יצרן:

D-Link

קישור לאתר יצרן

The D-Link DVS-310-1 1-channel H.264 PoE Video Encoder is a high-performance, single channel video encoder for integrating an existing analog CCTV (closed circuit television) camera into an IP-based video surveillance system. It is an ideal choice for banks, airports, factories, government buildings, prisons, and traffic surveillance applications - any location where surveillance equipment is already installed and functioning.

הצעת מחיר

מפרט

מידע

מפרט

סביבת שימוש

פנימי - Indoor

הזנת חשמל על כבל רשת

כן

MicroSD slot

כן

מידע

Video algorithms supported
• Simultaneous multi-profile support (H.264, MJPEG, MPEG4)
• Simultaneous multi-profile support for web viewing, 3G mobile viewing, and video recording
• JPEG compression for still images

Supported resolutions
• NTSC: D1 (720x480), CIF (352x240), QCIF (176x120)
• PAL: D1 (720x576), CIF (352x288), QCIF (176x144)

Analog video input
• 1CH, NTSC/PAL, BNC connector
• 1.0Vp-p with 75 Ω loading

Audio specifications
• Two-way audio
• External audio in
• External audio out
• G.726 Codec

Networking specifications
• Ethernet: RJ45 - 10/100 Base-TX
• 802.3af PoE
• Supported Protocols: IPv4, DHCP, ARP, DNS, TCP/IP, DDNS (D-Link), HTTP, HTTPS, UPnP™, Port Forwarding, Samba, SMTP, PPPoE, NTP (D-Link), FTP, RTP, RTSP, UDP, RTCP, ICMP, 3GPP

PTZ specifications
• Baud rates: 2400, 4800, 9600, 19200
• Connector: RS-485 for PTZ control

Removable storage
SD Card Slot

Minimum system requirements
• CPU: Pentium 4, 2.4 GHz and above
• Hard Disk: 40 GB or higher
• Memory: 512 MB or higher
• Video Resolution: 1024x768 (SVGA/XGA)
• Software: DirectX 9.0c or higher
• Browser: Microsoft IE 6.0 or higher
