Intel X299 Ultra Durable motherboard with RGB Fusion, Digital LED strip support, Dual M.2, 120dB SNR ALC1220, Intel Gaming LAN, USB 3.1 gen 2 Type-A
מפרט
ערכת שבבים
Intel X299
תושבת מעבד
2066
סוג זכרון
DDR4
תצורת לוח
ATX
חיבורי תקשורת
LAN 1 Gigabit
חיבור USB קדמי
USB 2.0
\ USB 3.1
RAID
0,1,5,10
כרטיס קול משולב
6 port
סלוטים DDR4
8
PCI-E x16
2
PCI-E x16 (x8) Slot
1
PCI-E x16 (x4) Slot
2
Thunderbolt
1 x Thunderbolt™ add-in card connector
USB 3.1
12
USB 2.0
4
ממשק אחסון
SATA3
\ M.2 PCIe
חיבורי SATA3
8
חיבורי M.2 PCIe
2
חריצי הרחבה
Trusted Platform Module - TPM
\ PCIe 4.0 x16 slot
\ PCI Express x16 slot, running at x4
\ PCI Express x16 slot, running at x8
אריזה
Retail - קופסה
מידע
- Supports Intel® Core™ X-Series Processor Family
- Quad Channel Non-ECC Unbuffered DDR4, 8 DIMMs
- Intel® Optane™ Memory Ready
- Intel® VROC ready
- ASMedia 3142 USB 3.1 Gen 2 with USB Type-A
- 3-Way Graphics Support
- Server-Class Digital Power Design
- ALC1220 120dB SNR HD Audio with Smart Headphone AMP and WIMA audio capacitor
- RGB FUSION support Digital LED and RGBW Light Strips
- Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
- Dual Ultra-Fast M.2 with PCIe Gen3 x4 interface
- NVMe PCIe Gen3 x4 U.2 support by optional adaptor
- Intel GbE LAN Gaming Network with cFosSpeed Internet Accelerator Software
- Anti-Sulfur Resistor Design
- Ultra Durable™ 25KV ESD and 15KV Surge LAN Protection
- Lightning-Fast Intel® Thunderbolt™ 3 AIC Support
- GIGABYTE UEFI DualBIOS™
- APP Center Including EasyTune™ and Cloud Station™ Utilities
| Set the Color that Matches Your Style GIGABYTE's X299 series motherboards boast the most advanced LED system in the market today. With more customizability than ever and a convenient and intuitive UI thanks to the RGB Fusion App, you’ll have a blast making your GIGABYTE your own. For a more functional use, the bright and vibrant LEDs can be configured to display the PC’s temperature or load. For even more LED goodness RGBW strips are now supported for more true and vibrant whites. |
 |
 |
ALC 1220 120dB SNR HD Audio The ALC1220 is a high-performance multi-channel High Definition Audio Codec with up to 120dB SNR for crystal clear audio and features such as Smart Headphone Amp, 114dB SNR recording for precise voice chats and hardware decoding of DSD128, ensuring users get the best possible audio quality from their PC. |
| Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM and Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. |
 |
 |
Server-Class Digital Power Design GIGABYTE X299 series motherboards use an all digital CPU power design which includes both digital PWM Controllers and Smart Power Stage controllers. These 100% digital controllers offer incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from their new Intel® Core™ X-series CPUs. |
| Dual Ultra-Fast NVMe PCIe Gen3 x4 M.2 With two NVMe PCIe Gen3 x4 M.2 connectors onboard, GIGABYTE brings to the user PCI-Express connectivity for SSD devices. Delivering up to 32 Gb/s data transfer speed per connector, the dual M.2 provides an ideal storage solution as it also supports RAID modes. |
|
