Gigabyte Brix Barebone GB-BLCE-4000RC




3 שנים


Features Intel® Celeron® Processor N4000. Fanless design for embedded applications. Ultra compact PC design at only 0.67L (56.22 x 103 x 116.52mm). 1 x SO-DIMM DDR4 slot. Intel® IEEE 802.11ac, Dual Band Wi-Fi & Bluetooth 4.2. Dual HDMI (2.0a+1.4b) Outputs (Supports dual displays). 4 x USB 3.0 (1* USB Type-C™). Gigabit LAN. Headphone and Microphone Jack. VESA Mounting Bracket (75 x 75mm + 100 x 100mm).


דגם מעבד

Intel® Celeron® Processor N4000 2.6GHz, 2 core (TDP 6W)

סדרת מעבד (CPU)

Intel Celeron Dual Core

סוג זכרון


גודל זיכרון (סה"כ RAM)

לא כלול - עד 8 ג'יגה

חריצי זיכרון

נפח איחסון

לא כלול, צריך להוסיף 2.5"

כרטיס מסך משולב

Intel® UHD Graphics 600

USB Type-C

USB 3.0

חיבור גרפי


כרטיס קול משולב

2 port

חיבורי תקשורת

Bluetooth 4
\ LAN 1 Gigabit
\ Wi-Fi 5 (802.11ac)

סוג דיסק



The Perfect Fit for Any Space
Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with pure black stylish chassis design. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity and convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit.
Intel® Pentium® Silver and Celeron® Processor
GIGABYTE BRIX supports Intel third-generation low-power quad-core SoC processors which feature power-efficient 10W Intel Celeron models. From a simple internet access point to a high end multimedia station, the GIGABYTE BRIX a broad range of usage scenarios and the ultimate space flexibility. GIGABYTE BRIX is expected to deliver up to 23% improvement in productivity over previous generation.
RS232 COM Port Support
GIGABYTE BRIX is equipped with 1 x COM Port to support RS232, it can be easily used in a variety of commercial applications, such as Security system, Vending machine,  ATM system, KIOSK, and so on.
Support DDR4 Memory
GIGABYTE BRIX provides a 128-bit memory controller that supports DDR4 at up to 2400MHz. DDR4 is a type of synchronous dynamic random-access memory with a double data rate and high bandwidth interface. The primary advantages of DDR4 over its predecessor, DDR3, include higher module density and lower voltage requirements, coupled with higher data rate transfer speeds.
VESA Support
Bundled with a VESA bracket, the GIGABYTE BRIX™ can easily be mounted behind a monitor or HDTV, offering a simple and effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit.
